612 ERGOWAVE® active 2.1 ergonomic road bike saddle
Color:
900 black
Size:
12cm
Item-no. 57230-2032
:grayscale(false):quality(10):blur(20))
Key features
Power Transfer
Raised rear section stabilizes the pelvis and supports a focused, forward-leaning riding position.
Pressure Relief
Lowered nose and central relief zone create space at the front
for both women and men.
Dynamic Movement
The active system allows natural pelvic motion, promoting a smooth pedal stroke without compromising stability.
SPORTy FOCUS, PRECISE SUPPORT
The 612 ERGOWAVE® active 2.1 is built for riders who prefer a powerful, forward-leaning position. With its raised rear section, defined wave shape and dynamic active system, it delivers stable pelvic support and efficient pressure distribution – ideal for road cycling, XC and fast indoor training.
:grayscale(false):quality(10):blur(20))
active-Technology
Long-distance comfort
On long, performance-focused rides, every detail matters. SQlab’s active technology allows controlled lateral flex in the saddle, following the natural movement of the pelvis with each pedal stroke. This reliefs pressure on the spine, promotes disc mobility, and supports a healthy, ergonomic riding posture. Ideal for riders who spend long hours in the saddle – without compromising on comfort.
From now on, SQlab Active saddles are supplied exclusively with a medium elastomer. This helps us reduce overproduction, waste, and unnecessary use of resources, making an important contribution to greater sustainability.
The white and black elastomers for individual adjustment of the Active System remain available at no additional cost. The elastomer set can simply be added to the cart in the webshop if needed. The discount is applied automatically at checkout. Alternatively, it is also available from your specialist retailer.
The active 2.1 system supports dynamic pelvic movement and can help relieve the spine. Designed for long distances and high speeds, this saddle offers a balanced combination of comfort through ergonomics and performance enhancement through improved power transfer to the pedal.
Key Features:
ERGOWAVE® shape – Stable support and pressure relief in the perineal area
Sleek design – Designed for aggressive road/XC posture
active system 2.1 – Promotes disc movement, supports the spine
Fiberglass-reinforced shell – Improves power transfer
Developed for long distances – Ideal for endurance riders
| ARTICLE NUMBER | 57230-2032 |
|---|---|
| BAR CODE | 4062695004387, 4062695004394, 4062695004400, 4062695004417, 4062695004424 |
| SIZE(S) IN CM (EFFECTIVE SADDLE WIDTH) | 12 / 13 / 14 / 15 / 16 |
| AREA OF USE | Road |
| WEIGHT(S) IN G | approx. 224 / 225 / 230 / 235 / 239 |
| LENGTH(S) IN MM | approx. 275 |
| EFFECTIVE HEIGHT IN MM | approx. 53 |
| ACTIVE TECHNOLOGY | Yes - Sport |
| MATERIAL RAILS | S-Tube (light stainless steel - hollow) |
| MATERIAL BASE | Glass Fibre reinforced Polyamide Compound (PA12 + GF) |
| MATERIAL PADDING | Superlight Foam |
| MATERIAL COVER | Superlight Microfibre |
| HARDNESS IN SQ-SHORE | 60 |
| RELIEF OF PERINEAL AREA IN % | 63 |
| MAXIMUM LOAD IN KG | 100 |
| MAXIMUM TORQUE IN NM | 18 |
| E-BIKE READY | Yes |
| DIN/ASTM CATEGORIES | 4, 6 / 4 |
| GENDER | Unisex |
