3OX Trial ltd. Team Trial handlebar

Color:

900 black

3OX Trial ltd. Team - 900 black

Size:

31.8

Not available
Find a Dealer
1% for the Planet Logo

Item-no. 57230-2328

sqlablenker3OXtrialltdteamTomomiNishikubo230112_CANYON_Launch_017_bear

3OX Trial ltd. Team

Our team rider Tomomi Nishikubo is known for his incredible control over his bike and his creative tricks. The timeless, simple but still classy design of the 6OX Trial ltd. Team Edition, is an upgrade for every bike. The shape of this model fits every trial bike, dirt bike and BMX.


sqlabtriallenker3OXtrialltdteamTOPP

Stable & light

Choosing the right handlebar is crucial when it comes to bike handling, especially in the Trials area. During the development process Fabio tested many handlebars to make the 3OX Trial as stable and light as possible.

sqlabtriallenker3OXtrialltdteamPT02

High cockpit

The 3OX Trial increases the front end considerably compared to normal handlebars due to its 84 mm rise. The cockpit height resulting from this combination makes it possible to shift the body‘s center of gravity effortlessly over the rear wheel to generate the right „pop“ for bunny hops and other tricks.

sqlabtriallenker3OXtrialltdteamMAIN

Back- & Upsweep

9° Backweep and 5° Upsweep ensure a physiologically correct transition between forearm and hand to create an elbow position that allows an active riding style. This way the hard impacts that occur during trial riding can be cushioned as gently as possible.

Specially designed for the technically demanding world of trial riding, the 3OX Trial Ltd. Team Handlebar combines maximum control, stability, and ergonomics. With its 84mm rise, it elevates the cockpit to facilitate weight transfer backwards – ideal for bunny hops, wheelies, and balance tricks. The combination of 9° backsweep and 5° upsweep supports a natural arm position and efficiently absorbs hard landings. Perfectly matched with the 8OX Trial Stem.

Key Features
84mm rise for optimal rear wheel weight transfer during tricks and jumps
9° backsweep and 5° upsweep for a natural hand-arm alignment and improved shock absorption
Lightweight and stable construction for maximum control in trial riding
730mm width for agile handling and precise steering
ARTICLE NUMBER57230-2328
BAR CODE4062695005179
AREA OF USETrial & BMX
WEIGHT(S) IN Gapprox. 330
MATERIALAluminum 7050
WIDTH(S) IN MM730
MAXIMUM CUTTING WIDTH IN MM690
RISE IN MM84
BACKSWEEP IN °9
UPSWEEP IN °5
DOWNSWEEP IN °-
CLAMP DIAMETER IN MM31.8
CLAMPING WIDTH STEM IN MMMin. 40 - Max. 58
MAXIMUM TORQUE IN NM8
MAXIMUM SYSTEM WEIGHT ALLOWED IN KG120
E-BIKE READYNo
DIN/ASTM CATEGORIES5
